756.

This edifice is inhabited [accessible] below and above, like San Sepolcro, and it is the same above as below, except that the upper story has the dome c d; and the  376

p. 51

lower has the dome a b, and when you enter into the crypt, you descend 10 steps, and when you mount into the upper you ascend 20 steps, which, with 1/3 braccio for each, make 10 braccia, and this is the height between one floor of the church and the other.

Above the plan on the same sheet is a view of the exterior. By the aid of these two figures and the description, sections of the edifice may easily be reconstructed. But the section drawn on the left side of the building seems not to be in keeping with the same plan, notwithstanding the explanatory note written underneath it: "dentro il difitio di sopra" (interior of the edifice above) 377 .

Before leaving this group, it is well to remark that the germ of it seems already indicated by the diagonal lines in the plans Pl. LXXXV No. 11 and No. 7. We shall find another application of the same type to the Latin cross in Pl. XCVII No. 3.


Click to enlarge


Footnotes

50:376 : The church of San Sepolcro at Milan, founded in 1030 and repeatedly rebuilt after the middle of the XVIth century, still stands over the crypt of the original structure.

51:377 1: The small inner dome corresponds to a b on the plan--it rises from the lower church into the upper-- above, and larger, rises the dome c d. The aisles above and below thus correspond (e di sopra come di sotto, salvoche etc.). The only difference is, that in the section Leonardo has not taken the trouble to make the form octagonal, but has merely sketched circular lines in perspective. J. P. R.
