795.

ON THE LENGTH OF BEAMS.

That beam which is more than 20 times as long as its greatest thickness will be of brief duration and will break in half; and

p. 99

remember, that the part built into the wall should be steeped in hot pitch and filleted with oak boards likewise so steeped. Each beam must pass through its walls and be secured beyond the walls with sufficient chaining, because in consequence of earthquakes the beams are often seen to come out of the walls and bring down the walls and floors; whilst if they are chained they will hold the walls strongly together and the walls will hold the floors. Again I remind you never to put plaster over timber. Since by expansion and shrinking of the timber produced by damp and dryness such floors often crack, and once cracked their divisions gradually produce dust and an ugly effect. Again remember not to lay a floor on beams supported on arches; for, in time the floor which is made on beams settles somewhat in the middle while that part of the floor which rests on the arches remains in its place; hence, floors laid over two kinds of supports look, in time, as if they were made in hills  407


Footnotes

99:407 : 19 M. RAVAISSON, in his edition of MS. A gives a very different rendering of this passage translating it thus: Les planchers qui sont soutenus par deux differentes natures de supports paraissent avec le temps faits en voute a cholli.
